container::OrderedList Class Reference

An ADT that represents a list of items. More...

#include <orderedlist.h>

Inheritance diagram for container::OrderedList:

[legend]

Collaboration diagram for container::OrderedList:

[legend]

List of all members.

Public Member Functions
virtual	~OrderedList ()
	Destructor.
void	append (Entity *entity)
	Add an Entity to the end of the list.
void	insertBefore (Entity *entity)
	Inserts the new Entity relative to the list cursor.
virtual ostream &	renderState (ostream &os) const
	Write the state of an Object for debugging and demonstration.
virtual const Info *	typeInfo () const
	Return the instance of Object::Info that describes the class of this object.
virtual Object *	clone (bool deepCopy=false) const =0
	A polymorphic copy constructor.
Static Public Attributes
static const Info *const	TYPE_INFO = Object::typeInfoFactory("OrderedList")
Protected Member Functions
	OrderedList ()
	OrderedList (const OrderedList &pattern)
virtual void	append_impl (Entity *entity)=0
	Called by a template method.
virtual void	insertBefore_impl (Entity *entity)=0
	Called by a template method.
Private Member Functions
void	setCount (int c)
	Hide from sub-classes.
void	incCount ()
	Hide from sub-classes.
void	decCount ()
	Hide from sub-classes.

---

Detailed Description

An ADT that represents a list of items.

An OrderedList maintains an order but no sorting is performed or enforced. It is left to the user of the class to order the list as desired with the provided mutators.

---

Constructor & Destructor Documentation

container::OrderedList::OrderedList

(

)

[protected]

{ }

container::OrderedList::OrderedList

(

const OrderedList &

pattern

)

[protected]

{ }

container::OrderedList::~OrderedList

(

)

[virtual]

Destructor.

{ }

---

Member Function Documentation

void container::OrderedList::append

(

Entity *

entity

)

Add an Entity to the end of the list.

No copy of the Entity is made; the list takes on the responsibility of deleting the Entity. The list relinquishes the responsibility to delete the Entity only if it is extracted from the list using extractCurrentEntity().

This method is a template function that enforces the correct value for count. Concrete sub-classes must implement append_impl(Entity*) to do the work of adding an Entity.

                                       {
   append_impl(entity);
   incCount();
}

Here is the call graph for this function:

Here is the caller graph for this function:

virtual void container::OrderedList::append_impl

(

Entity *

entity

)

[protected, pure virtual]

Called by a template method.

See also:

Details documented in OrderedList::append

Implemented in container::OrderedArrayList, and container::OrderedLinkedList.

Here is the caller graph for this function:

virtual Object* container::OrderedList::clone

(

bool

deepCopy = false

)

const [pure virtual]

A polymorphic copy constructor.

Implements container::List.

Implemented in container::OrderedArrayList, and container::OrderedLinkedList.

void container::OrderedList::decCount

(

)

[inline, private]

Hide from sub-classes.

Reimplemented from container::Container.

                          {
      Container::decCount();
   }

void container::OrderedList::incCount

(

)

[inline, private]

Hide from sub-classes.

Reimplemented from container::Container.

                          {
      Container::incCount();
   }

Here is the caller graph for this function:

void container::OrderedList::insertBefore

(

Entity *

entity

)

Inserts the new Entity relative to the list cursor.

Postcondition:

The new Entity is in the list located before the cursor

The cursor remains unchanged, pointing to the same, pre-existing Entity or to the tail of the list

                                             {
   insertBefore_impl(entity);
   incCount();
}

Here is the call graph for this function:

Here is the caller graph for this function:

virtual void container::OrderedList::insertBefore_impl

(

Entity *

entity

)

[protected, pure virtual]

Called by a template method.

See also:

Details documented in OrderedList::insertBefore

Implemented in container::OrderedArrayList, and container::OrderedLinkedList.

Here is the caller graph for this function:

ostream & container::OrderedList::renderState

(

ostream &

os

)

const [virtual]

Write the state of an Object for debugging and demonstration.

This method must not change the state of an Object; adding or removing debug statements should not change the behavior of a class. The implementation must be robust, e.g., NULL safe, etc. and work without an unrecoverable error for any state, excluding an Object's time of construction and destruction. It is not required for the implementation to be thread safe.

Precondition:

The Object has been fully constructed and is not in the process of destruction

Postcondition:

The state of the Object is unchanged

Reimplemented from container::List.

Reimplemented in container::OrderedArrayList, and container::OrderedLinkedList.

                                                    {
   return this->List::renderState(os);
}

void container::OrderedList::setCount

(

int

c

)

[inline, private]

Hide from sub-classes.

Reimplemented from container::Container.

                               {
      Container::setCount(c);
   }

const Object::Info * container::OrderedList::typeInfo

(

)

const [virtual]

Return the instance of Object::Info that describes the class of this object.

Instantiation of Object::Info is controlled by the protected method Object::typeInfoFactory(const string&). Each sub-class of Object should create one and only one instance of Object::Info.

Reimplemented from container::List.

Reimplemented in container::OrderedArrayList, and container::OrderedLinkedList.

                                              {
   return TYPE_INFO;
}

Here is the caller graph for this function:

---

Member Data Documentation

const Object::Info *const container::OrderedList::TYPE_INFO = Object::typeInfoFactory("OrderedList") [static]

Reimplemented from container::List.

Reimplemented in container::OrderedArrayList, and container::OrderedLinkedList.

---

The documentation for this class was generated from the following files:

• orderedlist.h
• orderedlist.cpp
